Application:
2X-5Two-stage rotary vane vacuum pump can be used in electronics, machinery, chemical industry, vacuum packaging, vacuum freeze drying, liquid crystal injection machine, refrigerant perfusion machine, central air conditioning, lighting, refrigeration, vacuum distillation, and various vacuum equipment and other related industries.
2X-5Two-stage rotary vane vacuum pump can be used alone; Also can be used as roots booster pump, oil diffusion vacuum pump, turbo molecular pump, condensing vacuum pump, molecular sieve adsorption pump, titanium sublimation pump, zirconium aluminum vacuum pump, titanium ion vacuum pump and titanium elastomer vacuum pump starter pump.
Features:
Low noise
Little vibration
Stable performance
Oil is increasing
Equipped with air ballast valve
An oil change is convenient
Scope of use:
2X-5Two-stage rotary vane vacuum pump can remove the general acid and alkaline gas with a small amount of water vapor occasions; Do not smoke containing small particles of toxic, flammable and easy to make vacuum pump oil deterioration of the harmful gas.
Main specifications:
|
Model |
2X-3 |
2X-5 |
|
Pumping speed(L/S) |
3 |
5 |
|
Ultimate pressure(≤Pa) |
With gas ballast |
6.7*10-2 |
6.7*10-2 |
Without gas
ballast |
6.7-1 |
6.7-1 |
|
Power(kw) |
0.4 |
0.75 |
|
Air inlet(mm) |
∅ 34 |
∅ 34 |
|
Speed(r/min) |
500 |
500 |
|
Weight(kg) |
45 |
62 |
|
Water-vapour pumping(g/h) |
100 |
100 |
|
Oil capacity(L) |
0.3 |
1.7 |
|
Size(mm) |
455*253*320 |
470*356*320 |
